Tare WeightDimensionLoading CapacityAxleRimTireSuspensionSpring leafKing pinSupport legMain beamSide beamLadderGooseneckBrake chamberABSTwist LocksValveLightVoltageReceptacleTool boxPaintingShipping Terms:
| About 8.5-13T |
| 12000mm-18000mm*2500mm-3500mm*1650mm Please indicate the working platform height and length. |
| 60T/80T/100T/120T |
| 13 T/16T, FUWA /BPW /Huajing Brand |
| 6.5-20/7.5-20/8.00-20/8.5-20 |
| 8.25R20/10.00R20/11.00R20/12.00R20 |
| Mechanical suspension (Germany Type or America Type) Or Air suspension (China brand or BPW brand ) |
| 90(W)mm*13(Thickness)mm*10 Layer or 100mm*12mm*12 |
| JOST brand 2.0 or 3.5inch bolts type or Welding type |
| JOST brand D200T or China brand 28Tons (Double speed) |
| Height: 450mm-520mm, upper plate is 14mm-25mm, middle plate is 8mm-12mm,down plate is 16mm-25mm ; Material is Q345B Steel . |
| 16mm -25mm channel steel ( Material is Q235steel ). |
| Manual or Hydraulic type |
| For choose |
| WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TKL brand); Two pieces of 45L air tanks |
| Optional |
| Four ,Eight or Twelve pieces (Lifting type or Twist Screw Type) |
| WABCO valve |
| LED light |
| 24V |
| 7 ways (7 wire harness) |
| One piece, 1m*0.5m*0.5m (Size can be choose freely)(equipped with 1 unit Tire spanner,1 unit gudgeon sleeve and 1 unit cranking bar) |
| Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
| By bulk cargo carrier, RORO or 40HQ container. |
