| Item | Components | Specification | Quantity |
| Cold Aggregate Feeding System | Aggregate hopper | Capacity: 6.5m3 Width:3.2m Loading height: 3.6m | 4 |
| Aggregate feeder | Belt Width:500mm | 1 | |
| Power: 1.5kw Capacity: 60-70t/h | 4 | ||
| Frequency converter | 1 | ||
| Belt aggregate collecting conveyor | Belt Width:650mm Motor power: 4kW | 1 | |
| Inclined belt conveyor | Belt Width:650mm Max. capacity: 60 Tons power: 4kw | 1 | |
| Vibrator on hopper wall | Power: 0.25kW | 1 | |
| Trailer frame | L17000xW2450xH4300mm | Single axle frame, 4 tires, Tire model 8.25R16 | |
| Drying Drum | Drum drier | Φ1.2m, Length:5.2m Max capacity: 60 Tons Per Hour | 1 |
| Rock wool insulation layer | Thickness: 50mm | 1 | |
| Motor on drying drum | Power: 11kw | 1 | |
| Temperature sensor | 1 | ||
| Trailer frame | L12000xW2450xH4500mm | Single axle frame, 4 tires, Tire model 8.25R16 | |
| Combustion System | Diesel or heavy oil burner/mechanical atomization | Rate fuel oil: 450kg/h | 1 |
| Automatic flame failure protection devices | 1 | ||
| Fuel pump protection | Power: 3 kw | 1 | |
| Diesel tank | 1 | ||
| Air blower | Power: 15kw | 1 | |
| Hot Aggregate Elevator | Motor with speed reducer | Power:5.5kw Anti-Reverse | 1 |
| Dust Removal System | Cyclone dust catcher(primary dust removal) | 1 | |
| Bag house dust catcher (secondary dust removal) | Dust emissions: ≤20mg/Nm³ Filtering area: 259m2 | 1 | |
| METAMAX bag | 240 | ||
| Screw conveyor (under cyclone dust catcher) | Motor power: 4kW | 1 | |
| Screw conveyor (disposal) | Motor power: 4W | 1 | |
| Induced draft fan | Power: 30kW | 1 | |
| Temperature sensor | 1 | ||
| Cold air valve | 1 | ||
| Trailer frame | L9000xW2450xH4300mm | Single axle frame, 4 tires, Tire model 8.25R16 | |
| Filler Supply System | Level indicator | 2 | |
| Temporary filler storage bin | Capacity: 0.7m3 | 1 | |
| Filler elevator | Power: 4kw | 1 | |
| Filler conveying Screw (from filler bin to elevator ) | power: 4kw | 1 | |
| Filler metering Screw (from temporary storage bin to metering bin) | power: 4kw | 1 | |
| Bitumen Supply System(Direct heating type Bitumen tank) | Bitumen tank | Capacity: 30m3 Direct heating | 1 |
| 1 set of asphalt pipe | 1 | ||
| Pump for bitumen circulation | Power: 5.5kW | 1 | |
| Pump for bitumen unload | Power: 7.5kW | 1 | |
| Bitumen unload tank | 2m3 | 1 | |
| Mixing Tower | Vibrating screen | 4 screen layers Motor power: 2*2.35KW | 1 |
| Hot aggregate storage bin | 10m³ | 1 | |
| Hot aggregate weighing bin | Volume: 700kg | ||
| Sensors | 3 | ||
| Bitumen weighing bin | Volume: 100kg | ||
| Sensors | 3 | ||
| Twin shaft paddle mixer | Capacity: 700kg/batch Mixing time 15~25s; Power: 30kW | 1 | |
| Bitumen spraying pump | Power:7.5 kw | 1 | |
| Trailer frame | L12000xW2500xH4500mm | Doubile axle frame, 8 tires, Tire model 8.25R16 | |
| Pneumatic System | Air compressor | Exhaust: 2.3Nm³/min power: 15kw | 1 |
| Air cylinder;magnetic valve | 1 | ||
| Control System | Electrical motor control system | ||
| Aggregate temperature control system | |||
| PLC burner control system | |||
| PLC weighing control system | |||
| PLC mixing control system | |||
| Control room | Size:3000mm*2200mm*2500mm(Corrugated board) | ||
| Control cabinet | |||
| Operating platform | |||
| Voltmeter | |||
| Ammeter | |||
| Printer | |||
| Touch screen 5.7” | |||
| 17″LED display | |||
| Air conditioner | |||
| Additional Supply | Accessories | set | 1 |
| Working tools | set | 1 | |
