DONGFENG 8000L 12000L Fuel Tank Truck

Cab		Dongfeng Captain single row cab, allowable 3 passengers, air conditioner is optional
Wheel Base		3800 mm
Front/rear wheel track		1750/1586 mm
Front/rear suspension		1180/1715 mm
Approach/departure angle		22/13°
Maximum speed		90 km/h
Engine	Model	B125 33 (Cummins engine）
	Emission	Euro 2
	Type	Diesel engine, 4 cylinders, in-line, 4-stroke, water-cooled, turbo inter-cooling
	Maximum power	125hp, rated power speed 2500rpm
	Displacement	3999 ml
	Max.torque	410 N.m
	Bore x stroke	Φ102×120 mm
Gear box		6DS60T-D, 6 speed forward 1 reverse.
Front axle		2.7 tons
Rear axle		5.5 tons
Drive form		4×2
Steering wheel		Left Hand Drive (LHD)
Tire		215/75R17.5 16PR
Tire quantity		6+1 units
Electric System		24V

Tank volume	8,000 L
Tank material	Carbon steel
Tank thickness	5mm
Standard configuration	Oil pump, European standard manhole,, two aluminum alloy flow valves, tool box, climbing ladder, fire extinguisher, 2 oil hoses.
Optional	Oil dispenser, pneumatic valve, API valve, flow meter, anti overflow sensor plug, oil and gas recovery system, divided into several bins.
