| Manhole Cover | Aluminum alloy API manhole cover, ∮500mm |
| Bottom Valve | Aluminum API Pneumatic Bottom Valve |
| Discharging Valve | Diameter is 3 or 4 inch |
| Compartments | Optional |
| Discharging Pipe | 4”rubber hose, 2 pcs, 6m/each |
| Cat Walk | With (Common model or special design) |
| Main Beams | Weldding design or Special design I beam, connected by bolts and nuts |
| Axle | 3 axles, FUWA brand |
| Landing Gear | CHINA BRAND 28T |
| King Pin | JOST 3.5 inch bolt-in king pin |
| Suspension | Air suspension |
| Leaf Spring | 90(W)mm*13(Thickness)mm*10 Layer |
| Pneumatic Braking System | WABCO RE 6 relay valve; Spring brake chamber; one piece of 45L air tanks. |
| Rim | 8.00-20China Brand |
| Tire | 11.00R20 Brand can be Optional |
| ABS | Optional |
| Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint |
| Accessories | One standard tool box |
| Shipping Terms | By Bulk Cargo ,RORO |
