Tourfine the Best Trucks and Machinery Supplier
| Driving type: | 8×4 |
| Drive type: | LHD |
| Cab: | HW76 lengthened cab with one sleeper, A/C |
| Engine: | WD615.47 (SINOTRUK) |
| Engine type:
| Diesel 4-stroke direct injection engine, 6-cylinder in-line with water cooling, turbo-charging & inter cooling |
| Displacement: | 9.726 liters |
| Max. output: | 371hp@2200rpm |
| Max torque: | 1500NM@1100-1600rpm |
| Bore/Stroke(mm): | 126/130 |
| Compression ratio: | 17:1 |
| Specific fuel consumption: | 193g/Kwh |
| Gear box:
| HW19710 (made by SINOTRUK) |
| Clutch: | 430 Diaphragm type |
| Steering: | ZF 8118 |
| Front axle: | HF9 9T (plate/disc brake) |
| Rear axle: | HC16, double reduction driving axle (drum brake) |
| Tyre: | 12.00R20 RADIAL tyre (13 UNITS) |
| Kerb. mass: | 14860kg |
| Total mass: | 31000kg |
| Wheel base (mm): | 1800+3500+1350 |
| Front overhang (mm): | 1500 |
| Rear overhang (mm): | 2095 |
| Front track (mm): | 2022/2042,2022/2041 |
| Rear track (mm): | 1830 |
| Approach angle: | 19 degree |
| Departure angle: | 18 degree |
| Dimension (mm): | 10245×2496×3400 |
| Body: | |
| Inner size(mm): | 7200x2300x1500 |
| Capacity: | 24.84CBM |
| Thickness of body steel(mm): | floor 8 side & back 6 |
| Tipping type: | front tipping type(in front of the body) HYVA tipping system Holland technology IS optional |
