Truck Mounted Crane/

ISUZU 4×2 FVR Truck with 10 Ton Crane

Condition: New
Steering: Left
Horsepower: 240HP
Fuel Type: Diesel
Emission Standard: Euro Ⅵ
Overall size: 9920 x 2490 x 3610mm

  • Product Details
  • Porduct Parameters
  • Packing & Delivery
  • Successful Case

ISUZU 4×2 FVR Truck with 10-Ton Crane

Designed for medium to heavy-duty lifting operations, powered by ISUZU’s reliable high-performance engine for strong power and excellent fuel efficiency.
The 4×2 drive structure ensures flexible and efficient handling, perfect for urban roads and construction sites.
Equipped with a 10-ton crane, it delivers outstanding lifting capacity with smooth and safe operation.
Widely used in construction, municipal maintenance, and logistics industries.
The truck features a durable structure and a comfortable cab to enhance overall work experience.
ISUZU FVR — Your ideal partner for efficient lifting tasks!

Miss Shilo
Senior sales
Tel./hatsApp:0086 17813710458
Beiiing Tourfine lmport and Export co., Ltd
Web.:www.trucksmachine.com
Punctual One-Stop Shipping Service, Makes Business Easier with Us

Model:QL1180EQFRY
Drive:4×2
Overall dimension:L:9000 / W:2500 / H:3660
Internal dimensions of cargo compartment railing(mm):L:6000/ W:2450 / H:600
GVW:18000KG
Curb mass:6300KG
Wheelbase(mm):5500 mm
Engine Model:4HK1-TCG61
Engine power:175Kw/240PS
Fuel type:Diesel
Emission:Euro VI
Tire:295/80R22.5 16PR
Cab:One row with a berth,
Standard roof
Cab allowable passengers:2
Other configurations:ABS system
Power steering
Reflective signage
Air conditioning system
Maintenance-free battery
Cargo Body Parameter4 Stages
Cargo box size:6000x2450x600mm
XCMG Crane parameters
Crane requirementsType/PositionStraight arm/front
craneXCMG brand with Model SQS250
Rotation angle360°Full rotation
Sub frameMaterial/plate thicknessLongitudinal beam: Q345/10mm
Cargo boxsize6000*2450*600mm
Max Lifting CapacityKGS10000
Max extension lengthMM12500
Max lifting heightMM14000
