Tourfine the Best Trucks and Machinery Supplier
| Brand | SAIC BRAND IVECO_HONGAYN （6*4） |
| Type | Dump Truck |
| Model | (Drive forms 6×4) |
| Appearance Dimension：Length (mm) | 8115 |
| Appearance Dimension：Width(mm) | 2500 |
| Appearance Dimension：Height (mm) | 3510 |
| Engine | CURSOR-9 380HP,EURO-3 |
| Gear Box | 12JS180T |
| Steering | ZF technology full hydraulic power assisted |
| Clutch | 420mm type single plate power boosted. |
| CAB | C9 380 IVECO-STRALIS CABIN |
| Max speed (km/h) | 90 |
| Empty Weight (kg) | 12630 |
| Front axle load (kg) | 6500 |
| Rear axle load (kg) | full cast reinforcement double reduce rear axle, no welding. 16000kgX2 |
| Fuel type | Diesel |
| Fuel tank capacity | 350L |
| Exhaust standard | Euro 3 |
| Number of axle | 3 |
| Wheel base (mm) | 3575+1400(mm) |
| Number of suspension spring | 9/12 |
| Number of tires | 10+1 |
| Type of tire | 12.00R20 |
| Longitudinal beam | 317mm Double 8mm+8mm, |
| lift cylinder system
| T Middle tipping system |
| Dimensions of lorry body | 5400×2300×1500（mm） |
| Thickness of body steel | Floor 8mm side 6mm rock type bucket |
