Tourfine the Best Trucks and Machinery Supplier
| Brand | IVECO_HONGAYN （8*4） |
| Type | Dump Truck |
| Model | (Drive forms 8×4) LHD |
| Engine | CURSOR-9 380HP,EURO-3 |
| Gear Box | 12JSD180T |
| Steering | ZF technology full hydraulic power assisted |
| Clutch | 420mm type single plate power boosted. |
| CAB | IVECO-STRALIS CABIN LONG CABIN SINGLE SLEEPER WITH AC |
| Front axle load (kg) | 6500 |
| Rear axle load (kg) | full cast reinforcement double reduce rear axle, no welding. 16000kgX2 |
| Fuel type | Diesel |
| Fuel tank capacity | 400L |
| Exhaust standard | Euro 3 |
| Number of axle | 4 |
| Wheel base (mm) | 1800+4175+1400mm |
| Number of suspension spring | 9/12 |
| Number of tires | 12+1 units |
| Type of tire | 12.00R20 Radial tire |
| Longitudinal beam | 317mm Double 8mm+8mm, |
| lift cylinder system
| Front tipping Hyva tipping system(Holland technology) front tipping is optional |
| Dimensions of lorry body | 8000*2300*1500（mm） |
| Whole dimension | 11035*2500*3510mm |
| Thickness of body steel | Floor 8 mm side 6mm |
