| Tank | Volume | 15m³ |
| Dimensions | Sectional shape: oval |
| Tank material and thickness | The material and thickness of the tank body: Q235B carbon steel, 5mm; the material and thickness of the head: Q235B carbon steel, 5mm |
| Wave breaker | Quantity: 3 (no warehouse divided); material thickness: Q235B carbon steel, thickness 5mm |
| Manhole cover | Quantity: 1 piece; diameter: 500mm; material; aluminum alloy six-jaw can mouth |
| Discharge port | One 2-inch self-draining port at the rear of the tank; one 2-inch pressure drain on the right side of the tank; one fire hydrant interface; |
| Climb the ladder | Welded independent climbing ladder at the tail of the tank |
| Top guard | Anti-skid walkways and aluminum alloy folding guardrails are installed on both sides of the top of the tank; anti-skid plates are installed on the top of the tank |
| Level gauge | The front part of the tank, plexiglass |
| Tube box | Pre-painting treatment: mechanical rust removal before painting |
| Water pump | model | self-priming sprinkler pump |
| Limited Data | 50m³/h |
| Lift | 110m |
| Water absorption depth | 6.5m |
| PTO | High-speed power take-off | The modifier is responsible for the installation |
| Spraying device | Spray type | Manual, with aluminum alloy high pressure spray gun |
| Work platform | position | Tank tail, size: length 900mm, width 1500mm |
| Toolbox | position | On the left side of the tank, there is a built-in roll of 20m fire belt with connecting shaft and spray gun |
| Subframe | Material | Made of Q235 carbon steel plate |
| Process requirements | Welding requirements | Adopt ternary gas shielded welding; ensure uniform and smooth welding seam, firm and reliable welding, no cracks, slag inclusion, welding penetration, welding leakage phenomenon, and prevent water leakage and water seepage |
| Painting requirements | Pre-painting treatment: mechanical rust removal before painting |
