| Cabin | Left rudder/half row | |
| Whole vehicle main dimensions | Overall dimensions (LxWxH)mm | 8905×2460×2820 |
| Wheel base(mm) | 5150 | |
| Weight data | Curb weight(kg) | 5470 |
| Gross vehicle weight（kg） | 22000 | |
| Persons in cab (persons) | 2 | |
| Engine | Model | YC6A240-33 |
| Emissions standards | Euro III | |
| Displacement（L） | 7.255L | |
| Rated Power | 177 | |
| Max torque | 900 | |
| Gearbox | Model | 8JS105TA |
| Clutch | Type | Single dry diaphragm spring |
| Front axle | Type | 5.5.T |
| Rear axle | Type/Mainreducetion ratio | 10T/4.875 |
| Suspension | Front suspension/Leaf spring number | Non-independent suspension longitudinal plate spring /10 |
| Rear suspension/Leaf spring number | Non-independent suspension longitudinal plate spring /10+8 | |
| Brake system | Service brake | Drum-type pneumatic brake |
| Parking brake | Barely able to brake | |
| Tank | Volume | 10-15m³ | |
| Dimensions | Sectional shape: oval | ||
| Tank material and thickness | The material and thickness of the tank body: Q235B carbon steel, 5mm; the material and thickness of the head: Q235B carbon steel, 5mm | ||
| Wave breaker | Quantity: 3 (no warehouse divided); material thickness: Q235B carbon steel, thickness 5mm | ||
| Manhole cover | Quantity: 1 piece; diameter: 500mm; material; aluminum alloy six-jaw can mouth | ||
| Discharge port | One 2-inch self-draining port at the rear of the tank; one 2-inch pressure drain on the right side of the tank; one fire hydrant interface; | ||
| Climb the ladder | Welded independent climbing ladder at the tail of the tank | ||
| Top guard | Anti-skid walkways and aluminum alloy folding guardrails are installed on both sides of the top of the tank; anti-skid plates are installed on the top of the tank | ||
| Level gauge | The front part of the tank, plexiglass | ||
| Tube box | Pre-painting treatment: mechanical rust removal before painting Using two-component paint, the total thickness of the paint film reaches 80μm, two primers + two top coats | ||
| Water pump | model | self-priming sprinkler pump | |
| Limited Data | 50m³/h | ||
| Lift | 110m | ||
| Water absorption depth | 6.5m | ||
| PTO | High-speed power take-off | The modifier is responsible for the installation | |
| Spraying device | Spray type | Manual, with aluminum alloy high pressure spray gun | |
| Work platform | position | Tank tail, size: length 900mm, width 1500mm | |
| Toolbox | position | On the left side of the tank, there is a built-in roll of 20m fire belt with connecting shaft and spray gun | |
| Subframe | Material | Made of Q235 carbon steel plate | |
| Process requirements | Welding requirements | Adopt ternary gas shielded welding; ensure uniform and smooth welding seam, firm and reliable welding, no cracks, slag inclusion, welding penetration, welding leakage phenomenon, and prevent water leakage and water seepage | |
| Painting requirements | Pre-painting treatment: mechanical rust removal before painting Using two-component paint, the total thickness of the paint film reaches 80μm, two primers + two top coats |
