Wheel Loader 4 Ton Front Loader XC948 with 2.4cbm Bucket

BrandL: XCMG
Model: XC948
Loading capacity: 4ton
Bucket capacity: 2.4cbm
Overall dimension: L7882*W3405*H2550mm

Item	XC948	Unit
Rated Bucket	m³	2.4
Rated load	Kg	4000
Operating weight	Kg	14500
Dumping height	mm	2810
Dumping distance	mm	1082
Wheel Base	mm	3050
Wheel track	mm	2020
Minimum ground clearance	mm	410
Length	mm	7882
height	mm	3405
Width	mm	2550
Dumping Angle	(°)	45
Maximum breakout force	kN	130
Maximum traction	kN	135
Tire center (turning radius)	mm	5200
Lifting time of boom	s	4.5
Total hydraulic cycle time	s	9.5
Tipping load (Maximum steering)	Kg	9000
Tipping load( Straight state )	Kg	11000
Engine Model	/	QSB6.7
Engine Rated Power	KW	142
Engine Rotate speed	r/min	2200
