with digger and loader XCMG XC760K Backhoe Loader

Description		Unit	Parameter value
Rated load		kg	750
Tipping load		kg	150
Operating weight		kg	3140
Maximum breakout force		kN	18
Engine	Manufacturer		Xinchai
	Model		4D27G31
	Rated power	Hp/kw	49.3/36.8
	Rated speed	rpm	2500
	Cooling mode		Water-cooling
Performance parameter	Operation mode		Mechanical & multi-function electronic control
	Tire standard		10-16.5
	Maximum speed	Km/h	14
Hydraulic system	Hydraulic flow rate	L/min	62.5
	Optional large flow	—
	Hydraulic pressure	bar	200
Maximum operating height		mm	3878
Bucket hinge pin height		mm	3057
Cabin top height		mm	1960
Maximum horizontal height of bucket bottom		mm	2851
Length without bucket		mm	2533
Length with bucket		mm	3310
Toppling angle		°	40
Maximum unloading height		mm	2375
Ground-bucket angle		°	30
Rotating angle of bucket at highest point		°	83
Unloading distance		mm	575
Wheel base		mm	1027
Departure angle		°	25
Ground clearance		mm	183
Front radius of turning circle (without bucket )		mm	1183
Front radius of turning circle (with bucket)		mm	2066
Rear radius of turning circle		mm	1564
Length of tail		mm	1005
Wheel track		mm	1380
Tire edge width		mm	1640
Bucket edge width		mm	1800
Bucket capacity (stacking height)		m³	0.45
Bucket capacity (tiling)		m³	0.35
Diesel tank capacity		L	80
Capacity of hydraulic oil tank		L	60
